Chain link fence, also called diamond mesh fence, is a type of woven fence usually made from galvanized or PVC coated steel wire.
It is one of the most widely used fencing fabrics, as it is available in various wire gauges and mesh sizes and can be suitable in different applications.
Chain link fence, also called diamond mesh fence, is a type of woven fence usually made from galvanized or PVC coated steel wire.
It is one of the most widely used fencing fabrics, as it is available in various wire gauges and mesh sizes and can be suitable in different applications.
Chain Link Roll Selvage
For the edge of the chain link mesh, there are mainly two options: knuckled edge and twisted (protruding) edge.
The twisted edge can increases the fencing security and it is more popular.
Xin Hui Chain link fence Features:
Low cost, easy installation
10-Year limited warranty
Chain Link Fence steel components available
Suitable to all kinds of surroundings.
Dimension of Galvanized Chain Link Mesh | |||
Mesh | Wire Diameter | Width | Length |
40mmx40mm | 1.8mm--3.0mm | 0.5m--4.0m | 5m-25m |
50mmx50mm | 1.8mm--3.5mm | 0.5m--4.0m | 5m-25m |
60mmx60mm | 1.8mm--4.0mm | 0.5m--4.0m | 5m-25m |
80mmx80mm | 2.5mm--4.0mm | 0.5m--4.0m | 5m-25m |
100mmx100mm | 2.5mm--4.0mm | 0.5m--4.0m | 5m-25m |
Dimension of PVC coated Chain Link Mesh | |||
Mesh | Wire Diameter | Width | Length |
40mmx40mm | 2.8mm--3.8mm | 0.5m--4.0m | 5m-25m |
50mmx50mm | 3.0mm--5.0mm | 0.5m--4.0m | 5m-25m |
60mmx60mm | 3.0mm--5.0mm | 0.5m--4.0m | 5m-25m |
80mmx80mm | 3.0mm--5.0mm | 0.5m--4.0m | 5m-25m |
100mmx100mm | 3.0mm--5.0mm | 0.5m--4.0m | 5m-25m |
